Table 6-7
Active/Cold Removal Procedure of Memory (continued)
Work
Order
Task Reference
13 Installing the CMU from which the
memory was removed, in the SPARC
M12-2S
"17.5.2 Installing the CMU"
14 Assembling the SPARC M12-2S from
which the memory was removed
"17.5.3 Restoring the Server"
15 Incorporating the SPARC M12-2S from
which the memory was removed into the
building block configuration
"10.4.1 Incorporating the SPARC
M12-2S
Into a Building Block
Configuration"
16 Diagnosing the SPARC M12-2S from
which the memory was removed (*3)
"10.5.1 Diagnosing the SPARC M12
Hardware"
17 Diagnosing the XBU and crossbar cable,
in the building block configuration, of the
SPARC M12-2S from which the memory
was removed
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
18 Incorporating the SPARC M12-2S into the
physical partition
"10.6.1 Incorporating the SPARC
M12-2S Into the Physical Partition Using
PPAR DR"
19 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
20 Checking the operating condition of the
physical partition and logical domains (*2)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
21 Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
*1 Observe the installation rules to remove memory. For details, see "2.2 Checking the Memory Configuration
Rules."
*2 Reconfigure logical domains as required. For details, see "Chapter 3 Operations for Domain Configuration" in
the Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Domain Configuration Guide.
*3 If the memory was removed from
a SPARC M12-2S with no PCIe cards mounted, no diagnosis is necessary
(because diagnosis was performed in the previous step).
6.2.5 Active/Cold Removal Workflow of the PCI
Expansion Unit
You can perform active/cold removal of a PCI expansion unit in the following
configuration:
■
Configuration connecting two or more SPARC M12-2S units to a physical partition
Table 6-8 shows the workflow for active/cold removal of a PCI expansion unit.
Chapter 6 FRU Removal Workflows 199
