Table 6-8
Active/Cold Removal Procedure of a PCI Expansion Unit
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Checking the logical domain assignment
status of CPU resources mounted in the
SPARC M12-2S requiring maintenance
"3.2.4 Checking the Assignment Status
of Resources" in the Fujitsu SPARC M12
and Fujitsu M10/SPARC M10 Domain
Configuration Guide
3 Checking the logical domain assignment
status of memory resources mounted in
the SPARC M12-2S requiring maintenance
"3.2.4 Checking the Assignment Status
of Resources" in the Fujitsu SPARC M12
and Fujitsu M10/SPARC M10 Domain
Configuration Guide
4 Releasing the logical domain assignment
of all the PCIe cards and HDD/SSD
mounted in the SPARC M12-2S requiring
maintenance and the PCI expansion unit
"9.3 Releasing I/O Resources From a
Logical Domain"
5 Releasing the HDD/SSD and PCIe cards
mounted in the SPARC M12-2S requiring
maintenance and the PCI expansion unit,
from the system
"9.4 Enabling the Removal of Hardware"
6 Releasing the SPARC M12-2S requiring
maintenance from the physical partition
"9.4.3 Dynamically Releasing the
SPARC M12-2S From the Physical
Partition"
7 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
8 Confirming that the physical partition
and logical domains continue operating
"9.2.1 Checking the Operation Status of
Physical Partitions
and Logical Domains"
9 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
10 Releasing the PCI expansion unit to be
removed and the link card
"11.3 Removing a Link Cable" in the PCI
Expansion Unit for Fujitsu SPARC M12 and
Fujitsu M10/SPARC M10 Service Manual
11 Removing the PCICS in which the link
card is mounted from the SPARC M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
12 Removing the link card from the PCICS "12.3.2 Removing a PCIe Card or PCIe
Card Filler"
13 Installing a PCIe card filler in the PCICS
from which the link card was removed,
and installing the PCICS in the SPARC
M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
14 Incorporating the SPARC M12-2S from
which the PCI expansion unit was
removed into the building block
configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration
"
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023200
