Table 5-10
Inactive/Hot Addition Procedure of a PCIe Card
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Powering off the physical partition
containing the SPARC M12-2S to which
to add a PCIe card
"9.5.1 Stopping a Specific Physical
Partition"
3 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL
Control Function"
4Removing the PCICS from the SPARC
M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
5
Removing the PCIe card filler of the PCICS "12.3.2 Removing a PCIe Card or PCIe
Card Filler"
6 Installing a PCIe card in the PCICS to
install it in the SPARC M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
7 Diagnosing the SPARC M12-2S that has
undergone maintenance
"10.5.1 Diagnosing the SPARC M12
Hardware"
8 Confirming that there is
no problem with
the added PCIe card
"10.5.3 Checking the FRU Status After
Maintenance"
9 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
10 Powering on the physical partition
containing the SPARC M12-2S that
underwent maintenance
"10.9.1 Starting the System With an
XSCF Command"
11 Assigning the I/O resource
to a logical
domain
"3.2 Operations and Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
5.3.2 Inactive/Hot Addition Workflow of the HDD/SSD
You can perform inactive/hot addition of the HDD/SSD in the following configuration:
■
Building block configuration where two or more physical partitions are operating
Before adding the HDD/SSD, see "Precautions for HDD/SSD addition" in "7.2
Precautions for FRU Expansion."
Table 5-11 shows the workflow for inactive/hot addition of the HDD/SSD.
Chapter 5 FRU Addition Workflows 165
