Note -
If you are replacing the OPNL of the SPARC M12-2S, first set the BB-ID value from the
note made in "16.3.3 Removing the OPNL," and then install the OPNL.
Note -
In the case of the SPARC M12-2, you cannot set a BB-ID value for the OPNL.
Figure 16-9
Removing the OPNL
16.4 Installing the HDDBPU or OPNL
This section describes the procedure for installing the OPNL or HDDBPU.
16.4.1 Installing the OPNL
1.
Connect the OPNL and HDDBPU.
After connecting the OPNL and HDDBPU via the connector, insert the OPNL
into the HDDBPU.
Chapter 16 Maintaining the HDD Backplane Unit and Operation Panel 429
