On
PCIBOX#1001/PSU#0 PSU - FEJD1212000616
CA01022-0750-D/ On
PCIBOX#1001/PSU#1 PSU - FEJD1212000621
CA01022-0750-D/ On
PCIBOX#1001/IOB IOBOARD 1310 PP123701KU
CA20365-B66X 009AH On
PCIBOX#1001/LINKBD BOARD - PP140801ZC
CA20365-B60X 009AD/7061035 On
PCIBOX#1001/FANBP FANBP - PP1229015U
CA20365-B68X 004AC On
BB#00-PCI#03 CARD 1310 PP13490468
CA20365-B59X 012AD/9999999 On
-----------------------------------------------------------------------------
---
PSB power off sequence started. [1200sec]
0..... 30..... 60..end
PSB powered off.
PSB Test Fault
---- -------
--------
00-0 Passed Normal
XSCF>
diagxbu -y -b 01 -p 0
XBU diagnosis is about to start, Continue?[y|n] :
y
Power on sequence started. [7200sec]
0..... 30..... 60..... 90..end
XBU diagnosis started. [7200sec]
0..... 30..... 60..... 90.....120.....150.....180.....210.....240.....|
270.....300.....330.....360.....390.....420...end
completed.
Power off sequence started. [1200sec]
0..... 30..... 60..... 90.....120end
completed.
*Note*
Please confirm the error of XBU by "showlogs error".
In addition, please confirm the
degraded of XBU by "showstatus".
10.5.2 Diagnosing the XBU and Crossbar Cable
This section describes the procedure for diagnosing the XBU and crossbar cable in a
building block configuration.
<Description of options>
-b: Specify the BB-ID of the released SPARC M12-2S (communication source).
-t: Specify the BB-ID of the released SPARC M12-2S (communication destination).
-p: Specify the PPAR-ID (communication destination).
(1) Communication destination PPAR is running (active addition)
The following execution example diagnoses the XBU and crossbar cable between the
SPARC M12-2S of BB#1 and the SPARC M12-2S operating in PPAR#0.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023350
