Table 5-27
System-Stopped/Cold Addition Procedure of the SPARC M12-2S
Work
Order
Task Reference
1 Powering off all physical partitions "9.5.2 Stopping All Physical Partitions"
2 Switching the mode switch on the OPNL
to Service (*1)
"2.3.2 OPNL Control Function"
3Removing the power cords of all the
SPARC M12-2S units
"9.8.2 Removing the Power Cords"
4 Connecting the added SPARC M12-2S "3.4.1 Mounting the SPARC M12-2S in a
Rack"
in the Fujitsu SPARC M12-2S
Installation Guide
5 Connecting the XSCF BB control cable
and crossbar cable to the added SPARC
M12-2S
Also connecting the XSCF DUAL control
cable if the added SPARC M12-2S will
operate as the standby XSCF
"Appendix A Lists of Cable Connections
in a Building Block Configuration"
6 Connecting the power cords of all the
SPARC M12-2S units (*2)
"10.1.1 Installing a Power Cord"
7Rebooting all the XSCF firmware rebootxscf(8) in the Fujitsu SPARC M12
and Fujitsu M10/SPARC M10 XSCF
Reference Manual
(Example: rebootxscf -a)
8 Diagnosing all the SPARC M12-2S units "10.5.1 Diagnosing the SPARC M12
Hardware"
9 Confirming that there is no problem with
the added SPARC M12-2S
"10.5.3 Checking the FRU Status After
Maintenance"
10 Configuring memory mirroring if
duplicating memory
"7.6 Configuring Memory Mirroring" in
the Fujitsu SPARC M12-2S Installation
Guide
5.6.6 System-Stopped/Cold Addition Workflow of the
SPARC M12-2S
You can perform system-stopped/cold addition of the SPARC M12-2S in the
following model:
■
Building block configuration connecting one or more SPARC M12-2S units
Before adding the SPARC M12-2S, see "Precautions for SPARC M12-2S addition" in
"7.2 Precautions for FRU Expansion." To mount the SPARC M12-2S to be added in a
rack, see "3.4.1 Mounting the SPARC M12-2S in a Rack" in the
Fujitsu SPARC
M12-2S Installation Guide.
Table 5-27 shows the workflow for system-stopped/cold addition of the SPARC
M12-2S.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023186
