Fujitsu Oracle SPARC M12-2 User Manual

Table 5-26
System-Stopped/Cold Addition Procedure of a PCI Expansion Unit
Work
Order
Task Reference
1 Powering off all physical partitions "9.5.2 Stopping All Physical Partitions"
2 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
3Removing the power cords of all the
SPARC M12-2/M12-2S units
"9.8.2 Removing the Power Cords"
4Removing the PCICS from the SPARC
M12-2/M12-2S
"12.3.1 Enabling the Removal of a
PCIe
Card"
5Removing the PCIe card filler from the
PCICS
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
6 Installing the link card in the PCICS "12.4.1 Installing a PCIe Card or PCIe
Card Filler"
7 Installing the link card in the SPARC
M12-2/M12-2S
"12.4.2 Incorporating a PCIe Card Into
the System"
8 Connecting a PCI expansion unit to the
link card
"4.2 Connecting Cables to the PCI
Expansion Unit" in the Fujitsu SPARC
M12-2 Installation Guide
or
"5.2 Connecting Cables to the PCI
Expansion Unit" in the Fujitsu SPARC
M12-2S Installation Guide
9 Installing a PCIe card in the PCI
expansion unit.
"12.4.1 Installing a PCIe
Card or PCIe
Card Filler"
10 Connecting the power cords of all the
SPARC M12-2/M12-2S units
"10.1.1 Installing a Power Cord"
11 Diagnosing the SPARC M12-2/M12-2S
with the added PCI expansion unit
"10.5.1 Diagnosing the SPARC M12
Hardware"
12 Confirming that there is no problem with
the added PCI expansion unit
"10.5.3 Checking
the FRU Status After
Maintenance"
13 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
14 Powering on all physical partitions "10.9.1 Starting the System With an
XSCF Command"
15 Assigning the I/O resource to a logical
domain
"3.2 Operations and Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC
M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
Chapter 5 FRU Addition Workflows 185
