(3)
(2)
(1)
Location
No.
Unit
1XSCF
BB
control
port
(XSCF0)
2XSCF
BB
control
port
(XSCF1)
3XSCF
BB
control
port
(XSCF2)
Figure
22-1
　　
Location
of
the
XSCF
BB
Control
Port
(SPARC
M12-2S)
22.2 Before
Maintenance
on
the
XSCF
BB
Control
Cable
When
replacing
the
XSCF
BB
control
cable,
perform
one
of
the
maintenance
procedures
listed
below.
　
-
4.2.15
Active/Cold
Replacement
Workflow
of
the
XSCF
BB
Control
Cable
-
4.4.17
Inactive/Cold
Replacement
Workflow
of
the
XSCF
BB
Control
Cable
-
4.6.16
System-Stopped/Cold
Replacement
Workflow
of
the
XSCF
BB
Control
Cable
　
When
implementing
a
building
block
configuration
by
connecting
multiple
SPARC
M12-2S
units
for
a
system
that
uses
only
one
SPARC
M12-2S
unit,
check
the
connection
destinations
of
the
XSCF
BB
control
cable
in
"Appendix
A
Lists
of
Cable
Connections
in
a
Building
Block
Configuration."
