Fujitsu Oracle SPARC M12-2 User Manual

Table 4-55
System-Stopped/Cold Replacement Procedure of the FANU (continued)
Work
Order
Task Reference
4 Stopping all physical partitions "9.5.2 Stopping All Physical Partitions"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6Removing the power cords of all the
SPARC M12-2/M12-2S units
"9.8.2 Removing the Power Cords"
7Removing the FANU from the SPARC
M12-2/M12-2S
"14.3.1 Removing a FANU"
8 Installing the FANU
in the SPARC
M12-2/M12-2S
"14.4.2 Installing a FANU"
9 Installing the power cords on all the
SPARC M12-2/M12-2S units
"10.1.1 Installing a Power Cord"
10 Diagnosing all the SPARC M12-2/M12-2S
units
"10.5.1 Diagnosing the SPARC M12
Hardware"
11 Confirming that there is no problem with
the replacement FANU
"10.5.3 Checking the FRU Status After
Maintenance"
12 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
13 Powering on the physical partitions "10.9.1 Starting the System With an
XSCF Command"
14 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-56
System-Stopped/Cold Replacement Procedure of the FANBPU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the FANBPU to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2/M12-2S that houses the
FANBPU to be replaced
"8.1.2 Checking Hardware"
4.6.5 System-Stopped/Cold Replacement Workflow of
the FANBPU
Before replacing the FANBPU, see "Precautions for FANBPU replacement" in "7.1
Precautions for FRU Replacement."
Table 4-56 shows the workflow for system-stopped/cold replacement of the FANBPU.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023136
