Table 4-51
System-Stopped/Hot Replacement Procedure of a PCI Expansion Unit
(continued)
Work
Order
Task Reference
7 Installing a FRU in the PCI expansion unit PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
8 Powering on the physical partitions "10.9.1 Starting the System With an
XSCF Command"
9 Confirming that there is no problem with
the replacement PCI expansion unit
"10.5.3 Checking the FRU Status After
Maintenance"
10 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
11 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
4.6 System-Stopped/Cold Replacement
Workflows
This section describes the workflows for system-stopped/cold replacement of the
FRUs mounted in the SPARC M12-2/M12-2S.
The described procedures are performed after all the SPARC M12-2/M12-2S units are
placed in the cold state, without using the maintenance menu.
Note that, in a building block configuration, you can perform maintenance using the
maintenance
menu when only the SPARC M12-2S requiring maintenance is in the
cold state. For work procedures with the maintenance menu, see "4.4 Inactive/Cold
Replacement Workflows."
The XSCF DUAL and XSCF BB control cables cannot be maintained by using the
maintenance menu.
Before performing replacement work, be sure to check the
notes on maintenance
work in the Fujitsu SPARC M12 Product Notes of the XCP version used.
Each of the following sections puts together the order of work and the tasks for each
FRU into a table. For details on each task, see the reference shown in the table.
The following FRUs are
subject to system-stopped/cold replacement:
■
XSCFU
■
PCIe card
■
PSU
■
FANU
■
FANBPU
Chapter 4 FRU Replacement Workflows 131
