Table 4-47
System-Stopped/Hot Replacement Procedure of a PCIe Card (continued)
Work
Order
Task Reference
3 Checking the operation status of the
SPARC M12-2/M12-2S that houses the
PCIe card to be replaced
"Table 2-21 PCIe Card Slot LEDs and
Their States"
4 Stopping all physical partitions "9.5.2 Stopping All Physical Partitions"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6Removing the faulty PCIe
card from the
SPARC M12-2/M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
7Removing the faulty PCIe card from the
PCICS
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
8 Installing the replacement PCIe card in
the PCICS to install it in the SPARC
M12-2/M12-2S
"12.4.1 Installing a PCIe Card or
PCIe
Card Filler"
9 Powering on the physical partitions "10.9.1 Starting the System With an
XSCF Command"
10 Confirming that there is no problem with
the replacement PCIe card
"10.5.3 Checking the FRU Status After
Maintenance"
11 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
12 Checking the operating condition
of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-48
System-Stopped/Hot Replacement Procedure of the PSU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the PSU to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2/M12-2S that houses the
PSU to be replaced
"Table 2-20 PSU LEDs and Their States"
4.5.3 System-Stopped/Hot Replacement Workflow of the
PSU
Before replacing the PSU, see "Precautions for PSU replacement" in "7.1 Precautions
for FRU Replacement."
Table 4-48 shows the workflow for system-stopped/hot replacement of the PSU.
Chapter 4 FRU Replacement Workflows 127
