(2)
(1)
Table 2-21
PCIe Card Slot LEDs and Their States
Location
No.
Name Color State Description
1 POWER Green On Indicates that power is being supplied.
- Off Indicates that power is not being supplied.
2 ATTENTION Amber On Indicates that an error has occurred.
Blinking Indicates that the unit (locator) requires
maintenance.
- Off Indicates the normal state.
PCIe card slot
Figure 2-15
LED Locations of the PCIe Card Slots
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 202334
