Table 4-39
Inactive/Cold Replacement Procedure of the BPU (continued)
Work
Order
Task Reference
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
7Placing the SPARC M12-2S requiring
maintenance into the cold state, and
removing the BPU from the SPARC M12-2S
"18.4 Removing the BPU and PSUBP"
8 Installing the BPU in the SPARC M12-2S,
and placing the SPARC M12-2S that
required maintenance into the hot state
"18.5 Installing the BPU and PSUBP"
9 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a
Building Block
Configuration"
10 Diagnosing the SPARC M12-2S requiring
maintenance (*1)
"10.5.1 Diagnosing the SPARC M12
Hardware"
11 Diagnosing the XBU and crossbar cable
of the SPARC M12-2S requiring
maintenance
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
12 Confirming that there is no problem with
the replacement BPU
"10.5.3 Checking the FRU Status After
Maintenance"
13 Switching the mode switch on the OPNL
to Locked, and powering on the physical
partition containing the SPARC M12-2S
that has undergone maintenance
"10.8 Powering on a Physical Partition"
14 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
*1 If the replaced BPU was in a SPARC M12-2S with no PCIe cards mounted, no diagnosis is necessary (because
diagnosis was performed in the previous step).
4.4.12 Inactive/Cold Replacement Workflow of the
PSUBP
You can perform inactive/cold replacement of the PSUBP in the following
configuration:
■
Building block configuration where two or more physical partitions are operating
Table 4-40 shows the workflow for inactive/cold replacement of the PSUBP.
Chapter 4 FRU Replacement Workflows 117
