Table 4-40
Inactive/Cold Replacement Procedure of the PSUBP
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the PSUBP to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S that houses the PSUBP to
be replaced
"8.1.2 Checking Hardware"
4 Powering off the physical partition
containing the
SPARC M12-2S that
houses the PSUBP requiring maintenance
"9.5.1 Stopping a Specific Physical
Partition"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
7Placing the SPARC
M12-2S requiring
maintenance into the cold state, and
removing the PSUBP from the SPARC
M12-2S
"18.4 Removing the BPU and PSUBP"
8
Installing the PSUBP in the SPARC M12-2S,
and placing the SPARC M12-2S that
required maintenance into the hot state
"18.5 Installing the BPU and PSUBP"
9 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
10 Diagnosing the SPARC M12-2S requiring
maintenance (*1)
"10.5.1 Diagnosing the
SPARC M12
Hardware"
11 Diagnosing the XBU and crossbar cable
of the SPARC M12-2S requiring
maintenance
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
12 Confirming that there is no problem with
the replacement PSUBP
"10.5.3 Checking the FRU Status After
Maintenance"
13 Switching the mode switch on the OPNL
to Locked, and powering on
the physical
partition containing the SPARC M12-2S
that has undergone maintenance
"10.8 Powering on a Physical Partition"
14 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
*1 If the replaced PSUBP was in a SPARC M12-2S with no PCIe cards mounted, no diagnosis is necessary
(because diagnosis was performed in the previous step).
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023118
