Table 4-48
System-Stopped/Hot Replacement Procedure of the PSU (continued)
Work
Order
Task Reference
4 Stopping all physical partitions "9.5.2 Stopping All Physical Partitions"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the PSU from the SPARC
M12-2/M12-2S
"9.6.3 Releasing the PSU"
7Removing the PSU from the SPARC
M12-2/M12-2S
"13.3 Removing a PSU"
8 Installing a PSU in the SPARC M12-2/
M12-2S
"13.4 Installing a PSU"
9 Incorporating the PSU into the SPARC
M12-2/M12-2S
"10.4.3 Incorporating the PSU"
10 Confirming that there is no problem with
the replacement PSU
"10.5.3 Checking the FRU Status After
Maintenance"
11 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
12 Powering on the physical partitions "10.9.1
Starting the System With an
XSCF Command"
13 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-49
System-Stopped/Hot Replacement Procedure of the FANU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the FANU to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2/M12-2S that houses the
FANU to be replaced
"Table 2-19 FANU LEDs and Their
States"
4 Stopping all physical
partitions "9.5.2 Stopping All Physical Partitions"
4.5.4 System-Stopped/Hot Replacement Workflow of the
FANU
Before replacing the FANU, see "Precautions for FANU replacement" in "7.1
Precautions for FRU Replacement."
Table 4-49 shows the workflow for system-stopped/hot replacement of the FANU.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023128
