Table 2-14
System Status Indicated by the Combination of LEDs
LED State Description
POWER XSCF
STANDBY
CHECK
Off Off Off The power is disconnected.
Off Off On The XSCF has detected an error before system start
or after system stop.
Off Blinking Off The XSCF is being initialized.
Off On Off The XSCF is in the standby state.
Or the system is waiting for power-on of the air
conditioning facilities (in the data center).
On On Off Warm-up standby processing is in progress. After
the
end of this processing, the system starts up.
Or the system startup processing is in progress.
Or the system is in operation.
On On On Although the system is operating normally, an error
has been detected.
Blinking On Off System stop processing is in progress. The FANU
stops after the processing ends.
2.4.2 System Locator
The field engineer or system administrator can identify which SPARC M12-2/M12-2S
needs maintenance, by looking at the CHECK LED (A in Figure 2-10) on the rear of
the SPARC M12-2/M12-2S. The CHECK LED is called the system locator and has the
same function as CHECK on the OPNL.
Note that it
is also used as the CHECK LED of the CMUL.
If this LED is on, check the operation status and error information of the
corresponding SPARC M12-2/M12-2S to determine whether it is on as a system
locator indication or to indicate a CMUL error.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 202328
