Table 4-24
Inactive/Hot Replacement Procedure of a PCIe Card
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the PCIe card to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S that houses the PCIe card
to be replaced
"Table 2-21 PCIe Card Slot LEDs and
Their
States"
4 Powering off the physical partition
containing the SPARC M12-2S that
houses the FRU requiring maintenance
"9.5.1 Stopping a Specific Physical
Partition"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6Removing the faulty PCIe card from the
SPARC M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
7Removing the faulty PCIe card from the
PCICS
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
8 Installing the replacement PCIe card in
the PCICS to install it in the SPARC M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
9 Powering on the physical partition
containing the SPARC M12-2S that
underwent maintenance
"10.8 Powering on a Physical Partition"
(*1)
10 Confirming that there is no problem with
the replacement PCIe card
"10.5.3 Checking the FRU Status After
Maintenance"
11 Switching the mode switch
on the OPNL
to Locked
"2.3.2 OPNL Control Function"
12 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
*1 Do not switch the mode switch on the OPNL to Locked at this point.
Table 4-24 shows the workflow for inactive/hot replacement of a PCIe card.
4.3.3 Inactive/Hot Replacement Workflow of the PSU
You can perform inactive/hot replacement of the PSU in the following configuration:
■
Building block configuration where two or more physical partitions are operating
Before replacing the PSU, see "Precautions for PSU replacement" in "7.1 Precautions
for FRU Replacement."
Table 4-25 shows the workflow for inactive/hot replacement of the PSU.
Chapter 4 FRU Replacement Workflows 99
