Table 6-13
Inactive/Cold Removal Procedure of a PCIe Card (continued)
Work
Order
Task Reference
9Removing the PCIe card from the PCICS "12.3.2 Removing a PCIe Card or PCIe
Card Filler"
10 Installing a PCIe card filler in the PCICS,
and installing the PCICS in the SPARC
M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
11 Incorporating the SPARC M12-2S from
which the PCIe card was
removed into
the building block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
12 Powering on the physical partition
containing the SPARC M12-2S that
underwent maintenance
"10.9.1 Starting the System With an
XSCF Command"
13 Confirming that there is no problem with
the system from which the PCIe card was
removed
"10.5.3 Checking the FRU Status After
Maintenance"
14 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
15 Checking the operating condition of the
physical partition and logical domains (*1)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
16 Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
*1 Reconfigure logical domains as required. For details, see "Chapter 3 Operations for Domain Configuration" in
the Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Domain Configuration Guide. If you have reconfigured a
logical domain, save the logical domain configuration information.
Table 6-14
Inactive/Cold Removal Procedure of the HDD/SSD
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Releasing the assignment of the I/O
resources of the HDD/SSD to be removed
"9.3 Releasing I/O Resources From a
Logical Domain"
6.4.2 Inactive/Cold Removal Workflow of the HDD/SSD
You can perform inactive/cold removal of the HDD/SSD in the following configuration:
■
Configuration connecting two or more SPARC M12-2S units to a physical partition
Before removing the HDD/SSD, see "Precautions for HDD/SSD removal" in "7.3
Precautions for FRU Reduction."
Table 6-14 shows the workflow for inactive/cold removal of the HDD/SSD.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023208
