Table 4-30
Inactive/Cold Replacement Procedure of a PCIe Card (continued)
Work
Order
Task Reference
14 Powering on the physical partition
containing the SPARC M12-2S that
underwent maintenance
"10.8 Powering on a Physical Partition"
(*1)
15 Confirming that there is no problem with
the replacement PCIe card
"10.5.3 Checking the FRU Status After
Maintenance"
16 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
17 Checking
the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
*1 Do not switch the mode switch on the OPNL to Locked at this point.
Table 4-31
Inactive/Cold Replacement Procedure of the PSU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the PSU to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S that houses the PSU to be
replaced
"Table 2-20 PSU LEDs and Their States"
4 Powering off the
physical partition
containing the SPARC M12-2S that
houses the FRU requiring maintenance
"9.5.1 Stopping a Specific Physical
Partition"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block
Configuration"
7Placing the SPARC M12-2S requiring
maintenance into the cold state
"9.8.2 Removing the Power Cords"
8
Removing the PSU from the SPARC M12-2S "13.3 Removing a PSU"
4.4.3 Inactive/Cold Replacement Workflow of the PSU
You can perform inactive/cold replacement of the PSU in the following configuration:
■
Building block configuration where two or more physical partitions are operating
Before replacing the PSU, see "Precautions for PSU replacement" in "7.1 Precautions
for FRU Replacement."
Table 4-31 shows the workflow for inactive/cold replacement of the PSU.
Chapter 4 FRU Replacement Workflows 107
