Table 4-18
Active/Cold Replacement Procedure of the BPU (continued)
Work
Order
Task Reference
6 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
7Placing the SPARC M12-2S requiring
maintenance into the cold state, and
removing the BPU from the SPARC M12-2S
"18.4 Removing the BPU and PSUBP"
8 Installing the BPU in the SPARC M12-2S,
and placing the SPARC M12-2S that
required maintenance into the hot state
"18.5 Installing the BPU and PSUBP"
9 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a
Building Block
Configuration"
10 Diagnosing the SPARC M12-2S requiring
maintenance (*1)
"10.5.1 Diagnosing the SPARC M12
Hardware"
11 Diagnosing the XBU and crossbar cable
of the SPARC M12-2S requiring
maintenance
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
12 Confirming that there is no problem with
the replacement BPU
"10.5.3 Checking the FRU Status After
Maintenance"
13 Incorporating the SPARC M12-2S that
required maintenance into the physical
partition
"10.6.1 Incorporating the SPARC
M12-2S Into the Physical Partition Using
PPAR DR"
14 Incorporating I/O resources of the SPARC
M12-2S requiring maintenance into a
logical domain
"10.7 Incorporating I/O Resources Into a
Logical Domain"
15 Checking the operating condition of
the
system and the I/O device usage status
"9.2 Checking the Operation Status and
Resource Usage Status of Oracle Solaris"
*1 If the replaced BPU was in a SPARC M12-2S with no PCIe cards mounted, no diagnosis is necessary (because
diagnosis was performed in the previous step).
4.2.12 Active/Cold Replacement Workflow of the PSUBP
You can perform active/cold replacement of the PSUBP in the following configuration:
■
Configuration connecting two or more SPARC M12-2S units to a physical partition
Table 4-19 shows the workflow for active/cold replacement of the PSUBP.
Chapter 4 FRU Replacement Workflows 91
