Table 4-44
Inactive/Cold Replacement Procedure of the XSCF DUAL Control Cable
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the XSCF DUAL control
cable to be replaced
"8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S connected to the XSCF
DUAL control cable to be replaced
"8.1.2 Checking Hardware"
4 Powering
off the physical partition
containing the SPARC M12-2S connected
to the XSCF DUAL control cable
requiring maintenance
"9.5.1 Stopping a Specific Physical
Partition"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the
SPARC M12-2S
From the Building Block Configuration"
7Placing the SPARC M12-2S requiring
maintenance into the cold state, and
removing the XSCF DUAL control cable
from the SPARC M12-2S
"21.3 Removing the XSCF DUAL
Control Cable"
8 Installing the XSCF DUAL control cable,
which is a maintenance part, on the
SPARC M12-2S, and
placing the SPARC
M12-2S that required maintenance into
the hot state
"21.4 Installing the XSCF DUAL Control
Cable"
9 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
10 Confirming that there is no problem with
the replacement XSCF DUAL control cable
"10.5.3 Checking the FRU Status After
Maintenance"
11 Switching the mode switch on the OPNL
to Locked, and powering on the physical
partition containing the SPARC M12-2S
that has undergone maintenance
"10.8 Powering on a Physical Partition"
12 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical
Partitions and Logical Domains"
4.4.17 Inactive/Cold Replacement Workflow of the XSCF
BB Control Cable
You can perform inactive/cold replacement of the XSCF BB control cable in the
Chapter 4 FRU Replacement Workflows 123
