Fujitsu Oracle SPARC M12-2 User Manual

(1)
(3)
(4)
(2)
Location No. Unit
1CPU memory unit lower (CMUL) (*2)
2CPU memory unit upper (CMUU) (*1) (*2)
3 Backplane unit (BPU)
4PSU backplane unit (PSUBPU)
*1 When purchased with no CMUU mounted, the SPARC M12-2/M12-2S has a CMU filler unit mounted.
*2 The CMUL and the CMUU together are collectively called the CMU.
2.1.3 Internal Units
Figure 2-3 shows the types and mounting locations of internal units.
Figure 2-3
Internal Units
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 202314
