Table 4-42
Inactive/Cold Replacement Procedure of the XBU (continued)
Work
Order
Task Reference
10 Diagnosing the XBU and crossbar cable
of the SPARC M12-2S requiring
maintenance
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
11 Confirming that there is no problem with
the replacement XBU
"10.5.3 Checking the FRU Status After
Maintenance"
12 Switching the mode switch on the OPNL
to Locked, and powering on the physical
partition
containing the SPARC M12-2S
that has undergone maintenance
"10.8 Powering on a Physical Partition"
13 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-43
Inactive/Cold Replacement Procedure of a PCI Expansion Unit
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the PCI expansion unit to be
replaced
"8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S connected to the PCI
expansion unit to be replaced
PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
4 Powering off the physical partition
containing the SPARC M12-2S connected
to the PCI expansion unit requiring
maintenance
"9.5.1 Stopping a Specific Physical
Partition"
4.4.15 Inactive/Cold Replacement Workflow of the PCI
Expansion Unit
You can perform inactive/cold replacement of a PCI expansion unit in the following
configuration:
■
Building block configuration where two or more physical partitions are operating
Table 4-43 shows the workflow for inactive/cold replacement of a PCI expansion unit.
Table 4-43 describes the procedure for replacing a FRU while the power cords of the
PCI expansion unit are disconnected.
For replacement procedures for FRUs while the power
cords of the PCI expansion
unit are connected, see "7.1.1 Hot Replacement" in the PCI Expansion Unit for Fujitsu
SPARC M12 and Fujitsu M10/SPARC M10 Service Manual.
Chapter 4 FRU Replacement Workflows 121
