Table 6-19
System-Stopped/Hot Removal Procedure of a PCIe Card (continued)
Work
Order
Task Reference
3 Releasing the I/O resources assigned to
the PCIe card to be removed
"9.3 Releasing I/O Resources From a
Logical Domain"
4 Confirming that you can release the PCIe
card to be removed
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
5Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
6 Powering off all physical partitions "9.5.2 Stopping All Physical Partitions"
7 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
8Removing the PCICS in which the PCIe
card to be removed is mounted from the
SPARC M12-2/M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
9Removing
the PCIe card to be removed,
from the PCICS
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
10 Installing a PCIe card filler in the PCICS,
and installing the PCICS in the SPARC
M12-2/M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
11 Powering on all physical partitions "10.9.1 Starting the
System With an
XSCF Command"
12 Confirming that there is no problem with
the system from which the PCIe card was
removed
"10.5.3 Checking the FRU Status After
Maintenance"
13 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
14 Checking the operating condition of the
system (*1)
"9.2.1
Checking the Operation Status of
Physical Partitions and Logical Domains"
15 Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
*1 Reassign I/O resources to logical domains as required. For details, see "3.2.18 Configuring an I/O Device" in
the Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Domain Configuration Guide.
6.5.2 System-Stopped/Hot Removal Workflow of the
HDD/SSD
Before removing the HDD/SSD, see "Precautions for HDD/SSD removal" in "7.3
Precautions for FRU Reduction."
Table 6-20 shows the workflow for system-stopped/hot removal of the HDD/SSD.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023216
