Fujitsu Oracle SPARC M12-2 User Manual

NAME SERVICE ID DEVICE MAC MODE PVID VID
MTU MAXBW LINKPROP
vnet1 primary-vsw4@primary 1 network@1 00:14:4f:fb:4d:fe 1
1500 (*1)
PEER MAC MODE PVID VID MTU
MAXBW LINKPROP
primary-vsw4@primary 00:14:4f:f8:42:2f 1 1500
DISK
NAME VOLUME TOUT ID DEVICE SERVER
MPGROUP
vdisk00 vdisk00@primary-vds0 0 disk@0 primary (*2)
(Omitted)
*1 The virtual network interfaces vnet0 and vnet1 are assigned as shown.
*2 The virtual disk vdisk00 is assigned as shown.
#
ldm list-io
NAME TYPE BUS DOMAIN STATUS
---- ---- --- ------ ------
PCIE0 BUS PCIE0 primary IOV
(*1)
(Omitted)
/BB0/PCI5 PCIE PCIE3 ldom OCC
(*2)
(Omitted)
/BB0/CMUL/NET0/IOVNET.PF0 PF PCIE0 primary
/BB0/CMUL/NET0/IOVNET.PF0.VF0 VF PCIE0 primary
(*3)
*1 The root complex PCIE0 is assigned as shown to the control domain.
*2 The PCIe endpoint of PCI slot #6 of BB#00 is assigned as shown to the logical domain ldom.
*3 An I/O device with the SR-IOV virtual function enabled is assigned as shown to the control domain.
5.
Check the assignment status of I/O devices.
The following example shows execution of the command for checking the
assignment status of I/O resources to logical domains.
To perform maintenance on a PCIe card, write down the results output by the ldm
list-io command, because they will be needed later to restore
the system after the
maintenance.
9.2.3 Checking the Usage of the HDD/SSD
To check the usage of the HDD/SSD, log in to Oracle Solaris.
This section describes how to check the configuration information for both the ZFS
mirror volumes and the RAID volumes using the hardware RAID function of the
Chapter 9 Releasing FRUs From the System 269
