Table 4-31
Inactive/Cold Replacement Procedure of the PSU (continued)
Work
Order
Task Reference
9 Installing a PSU in the SPARC M12-2S,
and placing the SPARC M12-2S that
required maintenance into the hot state
"13.4 Installing a PSU"
"10.1.1 Installing a Power Cord"
10 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
11 Confirming that there is no problem with
the replacement PSU
"10.5.3 Checking the FRU Status After
Maintenance"
12 Switching the mode switch on the OPNL
to Locked, and powering on the physical
partition containing the SPARC M12-2S
that has undergone maintenance
"10.8 Powering on a Physical Partition"
13 Checking the operating condition of
the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-32
Inactive/Cold Replacement Procedure of the FANU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the FANU to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S that houses the FANU to
be replaced
"Figure 2-13 LED Locations on the
FANU"
4 Powering off the
physical partition
containing the SPARC M12-2S that
houses the FRU requiring maintenance
"9.5.1 Stopping a Specific Physical
Partition"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block
Configuration"
4.4.4 Inactive/Cold Replacement Workflow of the FANU
You can perform inactive/cold replacement of the FANU in the following configuration:
■
Building block configuration where two or more physical partitions are operating
Before replacing the FANU, see "Precautions for FANU replacement" in "7.1
Precautions for FRU Replacement."
Table 4-32 shows the workflow for inactive/cold replacement of the FANU.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023108
