Table 4-28
Inactive/Hot Replacement Procedure of a PCI Expansion Unit
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the PCI expansion unit to be
replaced
"8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S connected to the PCI
expansion unit to be replaced
PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
4 Powering off the physical partition
containing the SPARC M12-2S connected
to the PCI expansion unit requiring
maintenance
"9.5.1 Stopping a Specific Physical
Partition"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6Removing the FRUs in the faulty PCI
expansion
unit
PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
7
Installing a FRU in the PCI expansion unit PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
8 Powering on the physical partition
containing the SPARC M12-2S that
underwent maintenance
"10.8 Powering on a Physical Partition"
(*1)
9 Confirming that there is no problem with
the replacement PCI expansion unit
"10.5.3 Checking the FRU Status After
Maintenance"
10 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
11 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
*1 Do not switch the mode switch on the OPNL to Locked at this point.
4.4 Inactive/Cold Replacement Workflows
This section describes the workflows for inactive/cold replacement of the FRUs
mounted in the SPARC M12-2S.
You can perform inactive/cold replacement only in the following system configurations:
■
Building block configuration where two or more physical partitions are operating
Before performing replacement work, be sure to check the notes on maintenance
work in the Fujitsu SPARC M12 Product Notes of the XCP version used.
Chapter 4 FRU Replacement Workflows 103
