Note -
You can replace, add, and remove PCIe cards.
Chapter 12
Maintaining PCIe Cards
This chapter describes the maintenance procedures for the PCIe cards mounted in the
SPARC M12 and the PCI expansion unit.
■
Locations of PCIe Cards
■
Before Maintenance on a PCIe Card
■
Removing a PCIe Card
■
Installing a PCIe Card
12.1 Locations of PCIe Cards
The SPARC M12-2 can house up to 11 PCIe cards, and the SPARC M12-2S can house
up to 8 cards. Figure 12-1 shows the mounting locations of PCIe cards.
383
