(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11)
(1) (2) (3) (4) (5) (6) (7) (8)
SPARC M12-2
SPARC M12-2S
Location No. Unit Slot
1PCIe card PCI#0
2PCIe card PCI#1
3PCIe card PCI#2
4PCIe card PCI#3
5PCIe card PCI#4
6PCIe card PCI#5
7PCIe card PCI#6
8PCIe card PCI#7
9 (*1) PCIe card PCI#8
10 (*1) PCIe card PCI#9
Figure 12-1
Mounting Locations of PCIe Cards in the SPARC M12
