Table 4-67
System-Stopped/Cold Replacement Procedure of the XSCF BB Control Cable
(continued)
Work
Order
Task Reference
6Removing the power cords of all the
SPARC M12-2S units, and removing the
XSCF BB control cable from the SPARC
M12-2S
"22.3 Removing the XSCF BB Control
Cable"
7 Installing the XSCF BB control cable on
the SPARC M12-2S, and installing the
power cords of all the SPARC M12-2S
units
"22.4 Installing
the XSCF BB Control
Cable"
8 Confirming that there is no problem with
the replacement XSCF BB control cable
"10.5.3 Checking the FRU Status After
Maintenance"
9 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
10 Powering on the physical partitions "10.9.1 Starting the System With an
XSCF Command
"
11 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-68
System-Stopped/Cold Replacement Procedure of a PCI Expansion Unit
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the PCI expansion unit to be
replaced
"8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2/M12-2S connected to the
PCI expansion unit to be replaced
PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
4 Stopping all physical partitions "9.5.2 Stopping All Physical Partitions"
4.6.17 System-Stopped/Cold Replacement Workflow of
the PCI Expansion Unit
Table 4-68 shows the workflow for system-stopped/cold replacement of a PCI
expansion unit.
Table 4-68 describes the procedure for replacing a FRU while the power cords of the
PCI expansion unit are disconnected.
For replacement procedures for FRUs while the power cords of the PCI expansion
unit are connected, see "7.1.1 Hot
Replacement" in the PCI Expansion Unit for Fujitsu
SPARC M12 and Fujitsu M10/SPARC M10 Service Manual.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023148
