Table 6-2
Active/Hot Removal Procedure of the HDD/SSD
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Checking the usage status of the
HDD/SSD to be removed
"9.2.3 Checking the Usage of the
HDD/SSD"
3 Releasing the HDD/SSD from the system
"9.4 Enabling the Removal of Hardware"
4 Confirming that you can remove the
HDD/SSD to be removed
"9.2.3 Checking the Usage of the
HDD/SSD"
5Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
6 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
7Removing the HDD/SSD from the
SPARC M12-2/M12-2S
"15.3.1 Removing an
HDD/SSD"
8 Checking the operating condition of the
physical partition and logical domains (*1)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
9 Installing the filler unit in the SPARC
M12-2/M12-2S
"15.4.2 Installing a Filler Unit"
10 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
*1 Reassign I/O resources to logical domains as required. For details, see "Chapter 3 Operations for Domain
Configuration" in the Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Domain Configuration Guide.
6.1.2 Active/Hot Removal Workflow of the HDD/SSD
Before removing the HDD/SSD, see "Precautions for HDD/SSD removal" in "7.3
Precautions for FRU Reduction."
Table 6-2 shows the workflow for active/hot removal of the HDD/SSD.
6.1.3 Active/Hot Removal Workflow of the PCI
Expansion Unit
Table 6-3 shows the workflow for active/hot removal of a PCI expansion unit.
Chapter 6 FRU Removal Workflows 191
