Fujitsu Oracle SPARC M12-2 User Manual

Caution -
When loosening the fixing screws, work carefully with the screwdriver so
as not to damage the PCIe cables, radiator cores (heat exchanging parts), and board
substrates inside.
A
Figure 14-4
Fixing Screws of the FANBPU
2.
Remove the FANBPU.
Hold the FANBPU by the parts indicated by A in Figure 14-5, and pull it out
from the server. When you see the "HANDLING POSITION" labels on the sides
of the FANBPU, hold the FANBPU by its sides and remove it
from the server.
Figure 14-5
Removing the FANBPU
Chapter 14 Maintaining the Fan Units and Fan Backplane Unit 407
