Table 5-9
Active/Cold Addition Procedure of the SPARC M12-2S
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
3 Incorporating the SPARC M12-2S into a
building block configuration (*1)
"10.3 Adding the SPARC M12-2S to a
Building Block Configuration
"
4
Diagnosing the added SPARC M12-2S (*2) "10.5.1 Diagnosing the SPARC M12
Hardware"
5 Diagnosing the XBU and crossbar cable
of the added SPARC M12-2S
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
6 Confirming that there is no problem with
the added SPARC M12-2S
"10.5.3 Checking the FRU Status After
Maintenance"
7 Configuring memory mirroring if
duplicating memory
"7.6 Configuring Memory
Mirroring" in
the Fujitsu SPARC M12-2S Installation
Guide
8 Adding the added SPARC M12-2S to the
PPAR configuration list for the physical
partition that is the incorporation
destination
"7.7 Creating a PPAR Configuration
List" in the Fujitsu SPARC M12-2S
Installation Guide
9 Assigning the SPARC M12-2S (system
board) to the physical partition
"7.8.1 Assigning
a Physical System
Board (PSB) to a Physical Partition
(PPAR)" in the Fujitsu SPARC M12-2S
Installation Guide
10 Incorporating the SPARC M12-2S into the
physical partition
"10.6.1 Incorporating the SPARC
M12-2S Into the Physical Partition Using
PPAR DR"
11 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
12 Assigning
the resources of the added
SPARC M12-2S to logical domains
"3.2 Operations and Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
*1 Connect cables by following the workflow of the addfru command.
*2 If a SPARC M12-2S with no PCIe cards mounted was added, no diagnosis is necessary (because diagnosis was
performed in the previous step).
To mount the SPARC M12-2S to be added in a rack, see "3.4.1 Mounting the SPARC
M12-2S in a Rack" in the Fujitsu SPARC M12-2S Installation Guide.
Table 5-9 shows the workflow for active/cold addition of the SPARC M12-2S.
Chapter 5 FRU Addition Workflows 163
