Table 2-4
Memory Installation Patterns (CMUL Only) in the SPARC M12-2/M12-2S (24
Memory Slots)
Memory Module Count Installed Memory
8a in Figure 2-6 --
16 a in Figure 2-6 c in Figure 2-6 -
24 a in Figure 2-6 c in Figure 2-6 e in Figure 2-6
Table 2-5
Memory Installation Patterns (CMUL and CMUU) in the SPARC M12-2/M12-2S (16 Memory
Slots)
Memory Module Count Installed Memory
8a in Figure 2-5 ---
16 a in Figure 2-5 b in Figure 2-5 --
24 a in Figure 2-5 b in Figure 2-5 c in Figure 2-5 -
32 a in Figure 2-5 b in Figure 2-5 c in Figure 2-5 d in Figure 2-5
Table 2-6
Memory Installation Patterns (CMUL and CMUU) in the SPARC M12-2/M12-2S (24 Memory
Slots)
Memory Module
Count
Installed Memory
8a in Figure
2-6
-----
16 a in Figure
2-6
b in Figure
2-6
----
24 a in Figure
2-6
b in Figure
2-6
c in Figure
2-6
---
32 a in Figure
2-6
b in Figure
2-6
c in Figure
2-6
d in Figure
2-6
--
40 a in Figure
2-6
b in Figure
2-6
c in Figure
2-6
d in Figure
2-6
e in Figure
2-6
-
48 a in Figure
2-6
b in Figure
2-6
c in Figure
2-6
d in Figure
2-6
e in Figure
2-6
f in Figure
2-6
When the CMUL and CMUU are mounted
When adding a CMUU
When installing memory by adding a CMUU to a chassis in which only the CMUL is
mounted, you do not need to remove the memory installed in the CMUL.
Install memory using an installation configuration from Table 2-7/Table 2-8 or Table
2-5/Table 2-6.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 202320
