Table 6-17
Inactive/Cold Removal Procedure of a PCI Expansion Unit
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Releasing the assignment of the I/O
resources of the PCIe cards mounted in
the PCI expansion unit to be removed
"9.3 Releasing I/O Resources From a
Logical Domain"
3 Confirming that you can remove
the PCIe
cards mounted in the PCI expansion unit
to be removed (*1)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
4Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
5 Powering off the physical partition
containing the SPARC M12-2S that is
connected to the PCI
expansion unit to be
removed
"9.5.1 Stopping a Specific Physical
Partition"
6 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
7 Releasing the SPARC M12-2S connected
to the PCI expansion unit to be removed,
from the building block configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block
Configuration"
8 Releasing the PCI expansion unit to be
removed and the link card
"11.3 Removing a Link Cable" in the PCI
Expansion Unit for Fujitsu SPARC M12 and
Fujitsu M10/SPARC M10 Service Manual
9Removing the PCICS in which the link
card is mounted from the SPARC M12-2S
"12.3.1 Enabling the Removal
of a PCIe
Card"
10 Removing the link card from the PCICS "12.3.2 Removing a PCIe Card or PCIe
Card Filler"
11 Installing a PCIe card filler in the PCICS,
and installing the PCICS in the SPARC
M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
12 Incorporating the SPARC M12-2S from
which
the PCI expansion unit was
removed into the building block
configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
13 Powering on the physical partition
containing the SPARC M12-2S that
underwent maintenance
"10.9.1 Starting the System With an
XSCF Command"
14 Confirming that there is no problem with
the system from
which the PCI expansion
unit was removed
"10.5.3 Checking the FRU Status After
Maintenance"
15 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
16 Checking the operating condition of the
physical partition and logical domains (*1)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Chapter 6 FRU Removal Workflows 213
