Table 4-34
Inactive/Cold Replacement Procedure of the HDD/SSD
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the HDD/SSD to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S that houses the HDD/SSD
to be replaced
"Figure 2-16 LED Locations on the
HDD/SSD"
4 Powering off the
physical partition
containing the SPARC M12-2S that
houses the HDD/SSD requiring
maintenance
"9.5.1 Stopping a Specific Physical
Partition"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block
Configuration"
7Placing the SPARC M12-2S requiring
maintenance into the cold state
"9.8.2 Removing the Power Cords"
8Removing the HDD/SSD from the
SPARC M12-2S
"15.3.1 Removing an HDD/SSD"
9 Installing an HDD/SSD in the SPARC
M12-2S
"15.4.1 Installing an HDD/SSD"
10 Placing the SPARC M12-2S that required
maintenance into the hot state
"10.1.1
Installing a Power Cord"
11 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
12 Diagnosing the SPARC M12-2S requiring
maintenance
"10.5.1 Diagnosing the SPARC M12
Hardware"
13 Powering on the physical partition
containing the SPARC M12-2S that
underwent maintenance
"10.8
Powering on a Physical Partition"
(*1)
14 Confirming that there is no problem with
the replacement HDD/SSD
"10.5.3 Checking the FRU Status After
Maintenance"
15 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
16 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical
Partitions and Logical Domains"
*1 Do not switch the mode switch on the OPNL to Locked at this point.
Chapter 4 FRU Replacement Workflows 111
