Table 5-15
Inactive/Cold Addition Procedure of the CMUU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Powering off the physical partition
containing the SPARC M12-2S requiring
maintenance
"9.5.1 Stopping a Specific Physical
Partition"
3 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
4 Releasing the SPARC
M12-2S requiring
maintenance from the building block
configuration, and removing the power
cords
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
"9.8.2 Removing the Power Cords"
5Removing the filler unit from the SPARC
M12-2S
"17.4 Removing the CMU or Memory"
6 Installing the CMUU in the SPARC
M12-2S (*1)
"17.5 Installing the CMU and Memory"
7 Installing the power cords on the SPARC
M12-2S with the added CMUU, and
incorporating it into the building block
configuration
"10.1.1 Installing a Power Cord"
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
8 Reconfiguring the I/O bus as required "3.2.18 Configuring an I/O
Device" in
the Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
9 Diagnosing the SPARC M12-2S with the
added CMUU (*2)
"10.5.1 Diagnosing the SPARC M12
Hardware"
10 Diagnosing the XBU and crossbar cable
of the SPARC M12-2S with the added
CMUU
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
11 Confirming that
there is no problem with
the added CMUU
"10.5.3 Checking the FRU Status After
Maintenance"
12 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
13 Powering on the physical partition of the
added CMUU
"10.9.1 Starting the System With an
XSCF Command"
14 Assigning the resources of the
added
SPARC M12-2S to logical domains
"3.2 Operations and Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
*1 If the CMUU has no memory installed, install memory before installing the CMUU in the SPARC M12-2S.
*2 If the CMUU was added to a SPARC M12-2S with no PCIe cards mounted, no diagnosis is necessary (because
diagnosis was performed two steps earlier).
Chapter 5 FRU Addition Workflows 171
