Fujitsu Oracle SPARC M12-2 User Manual

Table 6-4
Active/Cold Removal Procedure of a PCIe Card (continued)
Work
Order
Task Reference
5 Releasing the PCIe cards and HDD/SSD
mounted in the SPARC M12-2S requiring
maintenance, from the system
"9.4 Enabling the Removal of Hardware"
6 Confirming that you can release the
SPARC M12-2S
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
7 Releasing the SPARC M12-2S requiring
maintenance from the physical partition
"9.4.3 Dynamically Releasing the
SPARC M12-2S From the Physical
Partition"
8 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control
Function"
9 Confirming that the physical partition
and logical domains continue operating
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
10 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
11 Removing the PCICS in which the PCIe
card to be removed is mounted from the
SPARC M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
12 Removing the PCIe card from the PCICS "12.3.2 Removing a PCIe Card or PCIe
Card Filler"
13 Installing a PCIe card filler in the PCICS
from which the PCIe card was removed,
and installing
the PCICS in the SPARC
M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
14 Incorporating the SPARC M12-2S from
which the PCIe card was removed into
the building block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
15 Incorporating the SPARC M12-2S into the
physical partition
"10.6.1 Incorporating
the SPARC
M12-2S Into the Physical Partition Using
PPAR DR"
16 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
17 Checking the operating condition of the
physical partition and logical domains (*1)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
18 Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
*1 Reassign I/O resources to logical domains as required. For details, see "3.2.18 Configuring an I/O Device" in
the Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Domain Configuration Guide.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023194
