Table 6-6
Active/Cold Removal Procedure of the CMUU (continued)
Work
Order
Task Reference
5 Releasing the HDD/SSD and PCIe cards
mounted in the SPARC M12-2S requiring
maintenance, from the system
"9.4 Enabling the Removal of Hardware"
6 Releasing the SPARC M12-2S requiring
maintenance from the physical partition
"9.4.3 Dynamically Releasing the
SPARC M12-2S From the Physical
Partition"
7 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
8 Confirming that the physical partition
and logical domains continue operating
"9.2.1 Checking the Operation Status of
Physical Partitions
and Logical Domains"
9 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
10 Enabling the removal of the CMUU "17.4.1 Enabling the Removal of the
CMU"
11 Removing the CMUU from the SPARC
M12-2S
"17.4.2 Removing the CMU"
12
Installing a filler unit in the SPARC M12-2S "17.5.2 Installing the CMU"
13 Assembling the SPARC M12-2S from
which the CMUU was removed
"17.5.3 Restoring the Server"
14 Incorporating the SPARC M12-2S from
which the CMUU was removed into the
building block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
15 Diagnosing the SPARC M12-2S from
which the
CMUU was removed (*1)
"10.5.1 Diagnosing the SPARC M12
Hardware"
16 Diagnosing the XBU and crossbar cable,
in the building block configuration, of the
SPARC M12-2S from which the CMUU
was removed
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
17 Incorporating the SPARC M12-2S into the
physical partition
"10.6.1 Incorporating the SPARC
M12-2S
Into the Physical Partition Using
PPAR DR"
18 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
19 Checking the operating condition of the
physical partition and logical domains (*2)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
20 Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
*1 If the memory was removed from a SPARC M12-2S with no PCIe cards mounted, no diagnosis is necessary
(because diagnosis was performed in the previous step).
*2 Reconfigure logical domains as required. For details, see "Chapter 3 Operations for Domain Configuration" in
the Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Domain
Configuration Guide.
Chapter 6 FRU Removal Workflows 197
