Table 6-26
System-Stopped/Cold Removal Procedure of a PCI Expansion Unit
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Releasing the assignment of the I/O
resources of the PCIe cards mounted in
the PCI expansion unit to be removed
"9.3 Releasing I/O Resources From a
Logical Domain"
3 Confirming that you can remove
the PCIe
cards mounted in the PCI expansion unit
to be removed (*1)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
4Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
5 Powering off all physical partitions "9.5.2 Stopping All Physical Partitions"
6 Switching the mode switch on the
OPNL
to Service
"2.3.2 OPNL Control Function"
7Removing the power cords of all the
SPARC M12-2/M12-2S units
"9.8.2 Removing the Power Cords"
8 Releasing the PCI expansion unit to be
removed and the link card
PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
9Removing the PCICS in
which the link
card is mounted from the SPARC M12-2/
M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
10 Removing the link card from the PCICS "12.3.2 Removing a PCIe Card or PCIe
Card Filler"
11 Installing a PCIe card filler in the PCICS,
and installing the PCICS in the SPARC
M12-2/M12-2S
"12.4.1
Installing a PCIe Card or PCIe
Card Filler"
12 Installing the power cords of all the
SPARC M12-2/M12-2S units
"10.1.1 Installing a Power Cord"
13 Powering on all physical partitions "10.9.1 Starting the System With an
XSCF Command"
14 Confirming that there is no problem with
the system from which the PCI expansion
unit
was removed
"10.5.3 Checking the FRU Status After
Maintenance"
15 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
16 Checking the operating condition of the
physical partition and logical domains (*1)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
17 Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
*1 Reconfigure logical domains as required. For details, see "Chapter 5 Logical Domain Configuration Example"
in the Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Domain Configuration Guide.
Chapter 6 FRU Removal Workflows 225
