Fujitsu Oracle SPARC M12-2 User Manual

Table 9-4
Procedure for Dynamically Releasing a PCIe Endpoint
Step Operation Description Execution Location Command Used
1 Checking the assignment status of
PCIe endpoints
Control domain primary# ldm list-io
2 Releasing the PCIe endpoint assigned
to a logical domain
Control domain primary# ldm remove-io <device> <domain-
name>
3 Returning the PCIe endpoint to the
control domain or root domain
Control domain primary# ldm add-io <device> <domain-name>
4Confirming that the PCIe endpoint has
been returned to the control domain or
root domain
Control domain primary# ldm list-io
primary#
ldm list-io
NAME TYPE BUS DOMAIN STATUS
---- ---- --- ------ ------
(Omitted)
/BB1/PCI0 PCIE PCIE9 primary EMP
/BB1/PCI1 PCIE PCIE15 primary EMP
/BB1/PCI2 PCIE PCIE8 primary EMP
/BB1/PCI3 PCIE PCIE14 primary EMP
/BB1/PCI4 PCIE PCIE13 primary EMP
/BB1/PCI5 PCIE PCIE11 guest OCC
/BB1/PCI6 PCIE PCIE12 primary EMP
(Omitted)
primary#
ldm remove-io /BB1/PCI5 guest
primary#
ldm add-io /BB1/PCI5 primary
The following example executes the commands for releasing the PCIe endpoint from
logical domain guest to allow the PCIe card to be replaced.
1.
Check the assignment status of PCIe endpoints to logical domains.
In this example, PCI slot #5 of the SPARC M12-2S of BB-ID#01 is assigned to the
logical domain
guest.
2.
Release the PCIe endpoint from the logical domain.
Release PCI slot #5 of the SPARC M12-2S of BB-ID#01 from the logical domain
guest.
3.
Return the released PCIe endpoint to the control domain or root domain.
To remove a PCIe card or release a root complex by the PCI Hot Plug function,
you need to return the PCIe endpoint to the control domain or the root domain
beforehand.
Return PCI slot #5 of the SPARC M12-2S of BB-ID#01 to the control domain.
4.
Confirm that the target PCIe endpoint has been returned to the control
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023278
