3. PSU (Power Supply Unit)
4. XSCFU (Extended System Control Facility Unit)
------------------------------------------------------------------------------
Select [1-4|c:cancel] :
4
------------------------------------------------------------------------------
Maintenance/Replacement Menu
Please select a FRU to be replaced.
No. FRU Status
--- ------------------- --------------
1 /BB#0/XSCFU Degrade
------------------------------------------------------------------------------
Select [1|b:back] :
1
You are about to replace BB#0/XSCFU.
Do you want to continue?[r:replace|c:cancel] :
r
Communicate connection between the OS and XSCF might be disconnected.
When disconnect occurs, OS/ldmd's opereation that use connection will fail.
Do you want to continue?[y:yes|n:no] :y
Starting the preparation for shutting down XSCF [1/3]
0 done
Stopping the system control [2/3]
0 done
Shutting down XSCF [3/3]
0. done
Please execute the following steps:
1) Confirm the XSCF STANDBY LED of BB#0/XSCFU is not lit.
2) Remove BB#0/XSCFU.
3) After installing the exchanged device, please select [f:finish] :
5.
With a number key, select the faulty FRU.
Enter "1" since a fault has been confirmed in XSCFU of BB#0.
6.
Confirm that the selected FRU is displayed, and then enter "r".
7.
A message is output about replacing the FRU to be replaced. Begin
replacement.
After that, start the maintenance work for
the XSCFU. Do not enter "f" until you
complete the maintenance work.
After replacing the XSCFU, perform the work in "10.4.4 Incorporating the XSCFU"
to incorporate it into the system.
Chapter 9 Releasing FRUs From the System 317
