Fujitsu Oracle SPARC M12-2

Location
No.
Unit
1PCIe card (*1)
2XBU (*2)
3 Front cover
4FANU
5FANBPU
6 HDDBPU
7CMU filler unit (*3)
8CMU
*1 The SPARC M12-2 houses 11 cassettes, and the SPARC M12-2S houses 8 cassettes.
*2 This unit is mounted only in the SPARC M12-2S.
*3 This unit is mounted in a system that has only the CMUL when purchased.
(1)
(2)
Location
No.
Unit
1CMUL top cover
2Memory
Figure 17-2
Locations of Memory
Chapter 17 Maintaining the CPU Memory Unit and Memory 437
