Note -
To add memory or change the type of memory installed, follow the instructions in
"2.2.1 Memory Installation Rules."
Note -
When replacing only the CMU, make sure that the memory mounting position is the
same before and after the replacement of the CMU.
Note -
Confirm that the latches on both ends of the memory slot are closed. You need to
make sure that there is no unevenness (Figure 17-21) between the latches when seen from
directly above. If the latches are not closed, remove the memory and try installing it again.
1.
Install the memory.
Check that the latches on both sides of the memory slot into which to install
memory are open. Align the memory key grooves with the memory slot key,
and place the memory in the memory slot.
Figure 17-19
Installing Memory
2.
Secure the memory.
Push both ends of the memory
until the latches of the memory slot close.
Figure 17-20
Securing the Memory
Chapter 17 Maintaining the CPU Memory Unit and Memory 451
