Note -
For the SPARC M12-2, this step is not necessary.
Figure 17-31
Installing the Front Cover
4.
Install the XBU.
Install the XBU in the server and secure it by tightening the fixing screws. For
details, see "20.4 Installing an XBU." Note that, for the SPARC M12-2, this step
is not necessary. Proceed to step 5.
Figure 17-32
Installing the XBU
5.
Install
the PCIe card.
Install the PCICS to the server, and secure it by pushing down its removal levers.
Then, lower the cable support to secure the PCICS. For details, see "12.4.1
Installing a PCIe Card or PCIe Card Filler."
Chapter 17 Maintaining the CPU Memory Unit and Memory 459
