Note -
When installing the XBU, insert it all the way into the chassis, with its removal levers
open upward and downward. If you close the removal levers before inserting the XBU, you
cannot install it. The removal levers will move in the closing direction as you insert the XBU
all the
way into the chassis. Push the removal levers manually to close them completely.
Figure 20-7
Inserting the XBU
2.
Close the removal levers of the XBU.
Close the removal levers of the XBU, and connect the connector to the CPU
memory unit.
Figure 20-8
Connecting the XBU
3.
Secure the XBU.
Tighten the two fixing screws to secure the XBU.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023506
