Table 4-7
Active/Hot Replacement Procedure of a PCI Expansion Unit
Work
Order
Task Reference
1 Checking the operating condition of the
system and the I/O device usage status
"9.2 Checking the Operation Status and
Resource Usage Status of Oracle Solaris"
2 Releasing the assignment of PCIe cards
mounted in the PCI expansion unit
"9.3 Releasing I/O Resources From a
Logical Domain"
3 Enabling the removal of all the
PCIe
cards mounted in the PCI expansion unit
from the system
"9.4 Enabling the Removal of Hardware"
4Removing all the PCIe cards mounted in
the PCI expansion unit
"8.3 Removing a PCI Express Card" in
the PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
5 Enabling the removal of the link card
connected to the PCI expansion unit from
the system
"9.4 Enabling the Removal of Hardware"
6Removing the link card from the SPARC
M12-2/M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
7Removing the FRUs in the faulty PCI
expansion unit
PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
8
Installing a FRU in the PCI expansion unit PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
9 Incorporating the link card into the
system (*1)
"10.6.2 Incorporating an I/O Device Into
the Physical Partition by Using the Hot
Plug Function"
10 Installing all the PCIe cards that were
mounted in the PCI expansion unit
"8.4 Installing a
PCI Express Card" in
the PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
11 Incorporating all the PCIe cards installed
in the PCI expansion unit into the system
"10.6.2 Incorporating an I/O Device Into
the Physical Partition by Using the Hot
Plug Function"
12 Confirming that there is
no problem with
the replacement PCI expansion unit
"10.5.3 Checking the FRU Status After
Maintenance"
13 Restoring logical domains "10.7 Incorporating I/O Resources Into a
Logical Domain"
*1 The direct I/O function needs to be disabled. Remove all the PCIe cards mounted in the PCI expansion unit
when incorporating the link card into the system.
Chapter 4 FRU Replacement Workflows 75
