GD32F3x0 User Manual

588

0x4: f

ECCLK

HCLK

0x5: f

ECCLK

HCLK

0x6: f

ECCLK

HCLK

0x7: f

ECCLK

HCLK

Note:ECDIV[2:1] are located in TSI_CTL1 and ECDIV[0] is located in TSI_CTL0.

27:25

Reserved

Must be kept at reset value

CTCDIV[3]

Charge Transfer clock(CTCLK) division factor.

CTCLK in TSI is divided from HCLK and CTCDIV defines the division factor.

0000: f

CTCLK

HCLK

0001: f

CTCLK

HCLK

0010: f

CTCLK

HCLK

0011: f

CTCLK

HCLK

….

0111: f

CTCLK

HCLK

/128

1000: f

CTCLK

HCLK

/256

1001: f

CTCLK

HCLK

/512

….

1110: f

CTCLK

HCLK

/16384

1111: f

CTCLK

HCLK

/32768

Note: CTCDIV[3] is located in TSI_CTL1 and CTCDIV[2:0] are located in

TSI_CTL0.

23:0

Reserved

Must be kept at reset value
