GD32F3x0 User Manual

X101: Reserved

X110: Reserved

X111: Reserved

1.6.5. EXTI sources selection register 3 (SYSCFG_EXTISS3)

Address offset: 0x14

Reset value: 0x0000 0000

This register has to be accessed by word (32-bit).

Reserved

EXTI15_SS [3:0]

EXTI14_SS [3:0]

EXTI13_SS [3:0]

EXTI12_SS [3:0]

Bits

Fields

Descriptions

31:16

Reserved

Must be kept at reset value.

15:12

EXTI15_SS[3:0]

EXTI 15 sources selection

X000: PA15 pin

X001: PB15 pin

X010: PC15 pin

X011: Reserved

X100: Reserved

X101: Reserved

X110: Reserved

X111: Reserved

11:8

EXTI14_SS[3:0]

EXTI 14 sources selection

X000: PA14 pin

X001: PB14 pin

X010: PC14 pin

X011: Reserved

X100: Reserved

X101: Reserved

X110: Reserved

X111: Reserved

7:4

EXTI13_SS[3:0]

EXTI 13 sources selection

X000: PA13 pin

X001: PB13 pin

X010: PC13 pin

X011: Reserved
