GD32F3x0 User Manual

Reserved

EXTI11_SS [3:0]

EXTI10_SS [3:0]

EXTI9_SS [3:0]

EXTI8_SS [3:0]

Bits

Fields

Descriptions

31:16

Reserved

Must be kept at reset value.

15:12

EXTI11_SS[3:0]

EXTI 11 sources selection

X000: PA11 pin

X001: PB11 pin

X010: PC11 pin

X011: Reserved

X100: Reserved

X101: Reserved

X110: Reserved

X111: Reserved

11:8

EXTI10_SS[3:0]

EXTI 10 sources selection

X000: PA10 pin

X001: PB10 pin

X010: PC10 pin

X011: Reserved

X100: Reserved

X101: Reserved

X110: Reserved

X111: Reserved

7:4

EXTI9_SS[3:0]

EXTI 9 sources selection

X000: PA9 pin

X001: PB9 pin

X010: PC9 pin

X011: Reserved

X100: Reserved

X101: Reserved

X110: Reserved

X111: Reserved

3:0

EXTI8_SS[3:0]

EXTI 8 sources selection

X000: PA8 pin

X001: PB8 pin

X010: PC8 pin

X011: Reserved

X100: Reserved
